Compare Motherboards

Share Comparison

Motherboard	$188⁰⁹	$595⁹⁹
Chipset	Intel B860	AMD TRX50
Socket	LGA1851	sTR5
Form Factor	ATX	EATX
Max Memory	256 GB	1000 GB
Memory Type	DDR5	DDR5
Memory Slots	4	4
ECC Memory Support	No	Yes
PCIe x16 Slots	4	4
PCIe x16 4.0 Slots	4	1
PCIe x16 5.0 Slots	0	3
M.2 Slots	6	4
M.2 Slot Specifics	2260-2280M (PCIe4.0x4) 2280M (PCIe4.0x4) 2242-2260M (PCIe4.0x4) 2280M (PCIe4.0x4) 2260-2280M (PCIe4.0x4) 2280M (PCIe4.0x4)	25110M (PCIe5.0x4) 22110M (PCIe5.0x4) 22110M (PCIe5.0x4) 2280M (PCIe4.0x4)
SATA Ports	0	4
USB 2.0 Headers	2	4
USB 3.2 Headers	2	2
USB 3.2 (Gen 2) Headers	1	1
USB 4.0 Ports	0	2
WiFi	802.11 ax	802.11 ax
Ethernet Speed	5 Gbps	10 Gbps
Audio Chipset	Realtek	Realtek ALC4080
Audio Channels	7.1	2
Optical S/PDIF Out	No	Yes
BIOS Flashback	No	Yes
Color	Dark	Dark
Supported CPUs	Intel Core Ultra Series 2	Ryzen,7,8,9
M.2 Heatsink/Shields	-	Yes
Product Release	-	2023
	Amazon — Check Newegg — Check	Amazon — Check Newegg — Check

Comparison Analysis

Comparing the B860 PRO B860-P WIFI vs TRX50 AERO D reveals distinct differences in their targeted use cases.

The B860 PRO B860-P WIFI is the more budget-friendly option, costing approximately $408 (217%) less than the TRX50 AERO D.
